Factory Price 10W Zoom 15-36° Ultra-High Luminous Efficiency LED Shapeable Contour Track Light
Product Overview
The D1070K-3836B is a high-performance embedded contour spotlight from Kingfisher 2 Series featuring a 15-36° zoom optical lens for ultra-high-definition projection. It delivers 325-355LM output with excellent color rendering (Ra≥97) and supports 2700K-4000K CCT tuning. The spotlight enables millimeter-level precise light shaping with uniform illumination and ≤0.6% TV distortion. Its flexible design allows vertical 60° and horizontal 35° rotation for precise positioning. Compatible with smart control systems like DALI and Zigbee, it offers smooth dimming (0.01-100%) and tunable white light. The compact design integrates a φ75mm radiator, making it ideal for museums, galleries, retail spaces, and architectural lighting where accurate, distortion-free projection is essential.
Key Features
- Versatile Zoom Range - Features adjustable 15-36° beam angle for flexible lighting control, perfect for both focused accent lighting and wider area illumination.
- High-Quality Light Output - Delivers 325-355 lumens with Ra≥97 color rendering, ensuring vibrant, true-to-life colors for art and retail displays.
- Precision Beam Shaping - Enables millimeter-level light control with uniform distribution and sharp edges, ideal for architectural highlighting.
- Smart Lighting Integration - Compatible with DALI, Zigbee, and 1-10V dimming for seamless automation and tunable white light (2700K-4000K).
- Flexible Positioning - Offers 60° vertical and 35° horizontal rotation for precise aiming in museums, galleries, or commercial spaces.
- Compact Professional Design - Compact housing with φ75mm radiator combines high performance with discreet installation in premium applications.
Technical Specifications
| Item No. | D1070K-3836B |
|---|
| Power | 10W |
|---|
| Luminous Flux (3000K) | 300-350LM |
|---|
| Beam Angle (Lens Model) | Zoom 15-36° (3836B) |
|---|
| Ra | 97 |
|---|
| Color of Housing | Black, White |
|---|
| Dimension (mm) | Recessed housing Ø80×H130, Housing Ø38×H168.5 |
|---|
| Track Type | N/A |
|---|
Engineering Advantages
Cold Forging Integrated Radiator Design
A radiator made of 1070# pure aluminum and molded by molding pressure. It has high thermal conductivity, low-temperature differences, low light failure, and long service life. Thermal conductivity 226W/m.K
360° Manual Rotation Design
Loosen the manual screw and turn the lens to achieve the 360° spot rotation adjustment function. Device to solve the 360° rotation of the projection and light spot.
High-Definition Optical Lens Design
Formed by a plurality of high-definition coated optical lenses. The whole lamp has the characteristics of high luminous efficiency, high spot uniformity, minor distortion, extensive linear zoom range, good spot cut-off line, etc. A new optical path specially designed for COB light sources.
Optical-Grade Variable Aperture Design
An optical diaphragm made of high-precision special material with no blurring and freezing. Manual insertion and removal of the light cutting device can freely change the shape of the spot.
Multi-Layer Dry Damping Design
A focusing device not requiring the application of lubricating oil and has a silky feel. It is stable, reliable, wear-resistant, resistant to high temperatures, and does not wear off after extended use. Rotating the device can change the sharpness of the spot.
Linear Zoom Enhancement
Short stroke, considerable focal length, high short-focus and long-focus recognition, visible to the naked eye, linear zoom is enhanced and more convenient. Rotate the device to adjust the spot size.
Product Parameters
Application Scenarios
Museums & Art Galleries - Perfect for highlighting exhibits with ultra-sharp, high-CRI (Ra≥97) lighting, ensuring accurate color rendition and minimal distortion for delicate artworks.
Luxury Retail & Boutiques - Enhances product displays with precise beam control and uniform illumination, creating an inviting ambiance while showcasing merchandise vibrantly.
Hospitality & Restaurants - Elevates interior design with adjustable CCT (2700K-4000K) and smooth dimming, setting the right mood for dining areas, lobbies, or bars.
Architectural Accent Lighting - Ideal for illuminating facades, sculptures, or textured walls with distortion-free projection, maintaining clarity even at wide angles.
Event & Stage Lighting - Offers dynamic beam shaping and rotation for live performances or installations, blending high brightness with seamless smart control.
High-End Residential Spaces - Adds sophistication to homes with customizable lighting for art walls, staircases, or décor, combining aesthetics with smart-home convenience.
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: What do you sell?
A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.
Q2: Is it OK to print my logo on LED light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.
Q3: How to deal with the faulty?
A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
Q4: Can I have a sample order for LED light?
A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.
Q5: How long time to ship the goods if place an order?
A5: Usually 7 days for sample or small order, 15 working days for bulk order, but sometimes depend on the order quantity.
